• manufactured bylogo small
  • precipitation and temperature sensor transmitting data to internet via SigFox network
  • precipitation resolution 0.2 mm
  • intended for long-term monitoring
  • low maintenance and easy installation
  • indication of tilt
  • data visualization, archiving and downloading fully supported by EMScloud Internet application
  • long battery lifetime
  • Mini32 software support
  • Check sigfox

Specification

Temperature measuring interval 20 min
Precipitation sumation interval 10 min
Sending interval 60 min (10 min during rain event)
Collecting area 200 cm2
Precipitation resolution 0.2 mm
Battery lifetime more than 2 years
Temperature accuracy ± 0.15 °C
Protection rating IP68
Size (without supporting pin) 250 x 250 x 160 mm
Weight (without supporting pin) 680 g
Operating environment temperature  –40 to 60 °C
Operating environment humidity 0 to 100%

Online communication

Sigfox icon
  • internal tip counter ensures the correct absolute sum of precipitation independently on transmitter signal
  • for the most up-to-date information about precipitation the transmitting interval change to 10 min during raining event
  • data transmition performed via Sigfox protokol

Online data visualization on EMScloud website

A PI
  • measured values clearly displayed in graphs
  • online value agregation and integration
  • alerts about failures and unexpected events
  • view all data in web browsers on different devices
  • fast download in several formats

Mini32 software

Mini 32 P C app
  • graphically oriented software intended for work with long time series
  • fast calculation of hourly, daily, montly values
  • fast brief statistics
  • built-in efficient commands for summation and min-max-average calculation

Download

documentdocument 2 Datasheet
documentdocument 2 Maintenance notes
documentdocument 2 Maintenance notes CZ
documentdocument 2 Transmitter battery replacement instructions

Accessories
